Commercial Automated Gates Winnipeg
Folding gates are designed to save space and time. The quick open/close cycle helps to accurately control access at the busiest traffic environments. Folding Gates do not require as much room as other gates therefore saving valuable space for other uses. The compact installation allows effective security installations in the most confined spaces.
Folding gates are available in a variety of models to suit many applications and budgets. The gates have nearly limitless design options to match any project exterior. Factory assembly and testing ensures a smooth and reliable installation.
The FoldSmart SpeedGate
The FoldSmart SpeedGate is user friendly with 24 field programmable options.
Features
- Unlimited head room
- Energy efficient
- Cost effective
- Minimal footprint
- Variable frequency drive
Applications
- Parkades
- Storage facilities
- Commercial/industrial applications
Options
- Tailgate detection and anti-tailgate
- Traffic lights (bi-directional)
- Internal battery backup
- Safety photo cell
- Strobe light
- Detection loops
- Cold-weather kit
Technical Specifications
| Technical Data | FoldSmart Specifications |
|---|---|
| Max Height | 10' |
| Max Width | 30' |
| Opening Speed | 8 seconds |
| Finish | Hot dip galvanized, Powder coat options |
| Power Requirements | Voltage 115-230 V, Frequency 50/60 HZ, Current 15 AMP dedicated circuits |
| Hydraulic Option | No |
| Battery Back-up | Standard |
Listed to UL 325 (class 1, 2, 3 & 4)
Downloads
- FoldSmart Bi Folding Speedgate XT - Brochure (PDF 0.5MB)
- FoldSmart Bi Folding Speedgate XT - Specifications (Word 0.28MB)
- FoldSmart Bi Folding Speedgate XT - Specifications (PDF)
- FoldSmart Bi Folding Speedgate XT - Drawing (PDF 2.7MB)
- FoldSmart Bi Folding Speedgate XT 2-Fold (C1)
- FoldSmart Bi Folding Speedgate XT 2-Fold (C2)
- Complete FoldSmart Reference Manual
- FoldSmart Bi Folding Speedgate XT - Specifications (PDF 0.28MB)
- FoldSmart Bi Folding Speedgate XT - CAD Drawing 1 of 6 (DWG 0.8MB)
- FoldSmart Bi Folding Speedgate XT - CAD Drawing 2 of 6 (DWG 1.7MB)
- FoldSmart Bi Folding Speedgate XT - CAD Drawing 3 of 6 (DWG 1.1MB)
- FoldSmart Bi Folding Speedgate XT - CAD Drawing 4 of 6 (DWG 1.6MB)
- FoldSmart Bi Folding Speedgate XT - CAD Drawing 5 of 6 (DWG 0.4MB)
- FoldSmart Bi Folding Speedgate XT - CAD Drawing 6 of 6 (DWG 0.5MB)
- Automatic Gate Lookbook
Gallery
FoldSmart Videos
FoldSmart Features & Benefits
FoldSmart Gate
FoldSmart Bi Folding Speedgate
Watch how the quick movement of the FoldSmart Bi Folding Speedgate helps move traffic in a secure and efficient manner while reducing the risk of tailgating.
Two Fold FoldSmart SpeedGate
Wallace and Wallace Two Fold FoldSmart SpeedGate is a cost-effective, energy efficient gate solution that requires a minimal footprint and a rapid open/close time.
